86 173448944905454 aluminum sheet plate block bar
Last Updated ：2023/06/13
Introduction of 5454 aluminum sheet plate block bar
The strength of 5454 aluminum sheet plate block bar is about 20% higher than that of 5052, and its characteristics are roughly the same as that of 5154, but its corrosion resistance in harsh environments is better than that of 5154.
Tensile strength σb (MPa): ≥215
Conditional yield strength σ0.2 (MPa): ≥85
Elongation δ10 (%): ≥10
Elongation δ5 (%): ≥12
Chemical composition of 5454 aluminum sheet plate block bar
Al: margin
Si ：≤0.25
Cu: ≤0.10
Mg: 2.4～3.0
Zn: ≤0.25
Mn: 0.50～1.0
Ti ：≤0.20
Cr: 0.05～0.20
Fe: 0.000～0.400
Note: Single: ≤0.05; Total: ≤0.15
Application of 5454 aluminum sheet plate block bar
The 5454 aluminum sheet plate block bar is used in the production of fuel tanks, tanker barrels, pipelines for marine facilities, automobile wheels, etc.
The strength of 5454 aluminum sheet plate block bar is about 20% higher than that of 5052, and its characteristics are roughly the same as that of 5154, but its corrosion resistance in harsh environments is better than that of 5154.
Tensile strength σb (MPa): ≥215
Conditional yield strength σ0.2 (MPa): ≥85
Elongation δ10 (%): ≥10
Elongation δ5 (%): ≥12
Chemical composition of 5454 aluminum sheet plate block bar
Al: margin
Si ：≤0.25
Cu: ≤0.10
Mg: 2.4～3.0
Zn: ≤0.25
Mn: 0.50～1.0
Ti ：≤0.20
Cr: 0.05～0.20
Fe: 0.000～0.400
Note: Single: ≤0.05; Total: ≤0.15
Application of 5454 aluminum sheet plate block bar
The 5454 aluminum sheet plate block bar is used in the production of fuel tanks, tanker barrels, pipelines for marine facilities, automobile wheels, etc.
