5A06 Aluminum Block Features

The 5A06 aluminum block is Al-Mg rust-proof aluminum, and the 5A06 aluminum block has high strength and corrosion stability. The plasticity is good under annealing and extrusion. The weld tightness and weld plasticity of argon arc welding are still Yes, the welding joint strength of gas welding and spot welding is 90-95% of the strength of the matrix; the machinability is good.



5A06 Aluminum block chemical composition
Aluminum Al: balance
Silicon Si: ≤0.40
Copper Cu : ≤ 0.10
Magnesium Mg: 5.8 to 6.8
Zinc Zn: ≤ 0.20
Manganese Mn: 0.50 to 0.8
Titanium Ti: 0.02 to 0.10
铍 Be : 0.0001~0.005
Iron Fe: 0.000~ 0.400
Note: Single: ≤ 0.05; Total: ≤ 0.10

5A06 Aluminum block mechanical properties
Conditional yield strength σ0.2 (MPa): ≥160

The usage of 5A06 Aluminum block :
Excellent corrosion resistance makes the 5A06 aluminum block widely used in marine applications such as ships, as well as in automobiles, aircraft welding parts, subway light rails, pressure vessels that require strict fire protection (such as liquid tankers, refrigerated trucks, refrigerated containers), refrigeration units, and TV towers. , drilling equipment, transportation equipment, missile parts, armor, etc.
